Tianhui- one of the leading UV LED chip manufacturers and suppliers provides ODM/OEM UV led chip service.

Top Selling Tianhui 365nm Uv Led - 15

UV Wavelength:

250~260nm

Input Voltage:

4.8~7V

Color:

UVC

Input current:

20mA

Lead_Time:

Inquiry

Product details of the 365nm uv led

Product Information

The outline of 365nm uv led is neutral and can be accepted by a wide arrange of people. By adopting advanced technology, the quality of this product can be assured. Zhuhai Tianhui Electronic Co., Ltd. has always admired the principle of rigorous service.

Description

TH-UV255WP-TO46H

250~260NM uVC LED

Disinfection/Fluorescent Spectroscopy/

Chemical and Biological Analysis

Application

Disinfection

Fluorescent Spectroscopy

Chemical and Biological Analysis

Parameters

Item	Specifications
Model	TH-UV255WP-TO46H
Rated voltage	4.8~7V
UVC radiation flux	0.5~2.5mW
UVC Wavelength	250~260nm
Input current	20mA
Input power	0.1-0.14W
Working temperature	-10℃-85℃
Storage temperature	-40℃-100℃

Remarks

• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.

• Radiation flux（ Φ e) Measurement tolerance ± 10%.

• The measurement tolerance of forward voltage (VF) is ± 3%.

Usage method

Warning Instructions For Use

1. To avoid energy decay, keep the front glass clean.

2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.

3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.

4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not

recommended that the glue of the outlet hole of the module directly contact the drinking water.

5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged

6. Human safety

Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.

If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be

used to protect the body. Attach the following warning labels to products / systems

Company Feature

• Our company implements strict management on after-sales service of products. And it effectively improves the quality of after-sales service and enables every customer to enjoy the service right.
• Tianhui has a backbone team consisting of technical workers and management personnel of technique, production, quality inspection and others, which has made a strong guarantee for our continuous growth.
• Established in Tianhui has a good reputation in both domestic and foreign markets.
The discounts vary according to jewelry's styles. Feel free to contact Tianhui for details.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
