Tianhui uv photodiode sensor has been paid 100% attention from the selection of raw materials to production. The product has undergone a comprehensive quality check before shipment. Zhuhai Tianhui Electronic Co., Ltd. provides quality products for nearly thousands of hotels in many countries around the world to enhance the user experience.

Product Description

Next, Tianhui will present you with the specific details of uv photodiode sensor.

Tianhui Uv Photodiode Sensor for Sterilization 3

Description

High power UV LED series designed for high current operation, narrow radiation angles and high power output applications.

It combines advanced SMD design and low thermal resistance materials.

The CU3737 is an ideal UV light source for curing, printing and inspection applications.

Application

Tianhui Uv Photodiode Sensor for Sterilization 4

Printing	Dental Curing	UV Curing
Crime Inspection	Oil Leak Detection	*Fluorescence Photography*

Parameters

Item	Specifications
Model	CUN(x)UB1A series
Forward Voltage	360~370nm:3.7V 380~410nm:3.5V 415~425nm:3.6V
UVA radiation flux	360~370nm:0.9W 380~410nm:1.1W 415~425nm:1.0W
UVA Wavelength	360~370nm 380~410nm 415~425nm
Input current	700mA
Storage temperature	-40℃~100℃

Remarks

• Peak wavelength（ λ p) The measurement tolerance is ± 3nm.

• Radiation flux（ Φ e) Measurement tolerance ± 10%.

• The measurement tolerance of forward voltage (VF) is ± 3%.

Tianhui Uv Photodiode Sensor for Sterilization 5

Warning Instructions For Use

1. To avoid energy decay, keep the front glass clean.

2. It is recommended not to have objects blocking the light before the module, which will affect the sterilization effect.

3. Please use the correct input voltage to drive this module, otherwise the module will be damaged.

4. The outlet hole of the module has been filled with glue, which can prevent water leakage, but it is not

recommended that the glue of the outlet hole of the module directly contact the drinking water.

5. Do not connect the positive and negative poles of the module reversely, otherwise the module may be damaged

6. Human safety

Exposure to ultraviolet light can cause damage to human eyes. Don't look at ultraviolet light directly or indirectly.

If exposure to ultraviolet rays is unavoidable, appropriate protective devices such as goggles and clothing should be

used to protect the body. Attach the following warning labels to products / systems

Company Information

Zhuhai Tianhui Electronic Co., Ltd. is modern enterprise in the industry. And UV LED Module, UV LED System, UV LED Diode is a key product. With the corporate spirit of 'integrity, proactive service and excellence', our company is devoted to becoming a world-class company with global competitiveness. We are willing to cooperate with you sincerely to create a better future! Tianhui has a professional R&D team and an experienced technical team to promote the production of high-quality products. We have a professional team and can provide customers with the most appropriate solutions to help customers achieve their goals quickly and effectively.
Our products are all qualified and are sold directly from factory. Welcome friends from all walks of life to contact and consult us.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
